DESCRIZIONE

FR 1216 FIXED HAMMER MILL: OUR FLAGSHIP PRODUCT

The FR 1216 model is the most sought-after plant in our fixed hammer mill series, as it is designed and manufactured to meet the needs of small, medium-sized and large companies in the scrap metal industry. The FR 1216 plant stands out for its:

  • versatility;
  • ease of use.

fixed-hammer-mill-fr-1216
fr-1216-fixed-hammer-mill
treat-large-volumes-of-ferrous-materials
fixed-hammer-mill-model-1216
model-fr-1216-fixed-hammer-mill
custom-and-high-performance-fixed-hammers

FEATURES

DISCOVER THE FEATURES OF THE FR 1216 MODEL

At Parfer Siti, we design and manufacture custom and high-performance hammer mills, such as our FR 1216 model: with its functional characteristics and excellent performance, this is the plant our customers buy the most.

INCHES
48
DIMENSIONS (cm)
120 X 160
POWER HP
760 - 1000 (KW 560 - 710)

TECHNICAL DATA

FR 1216 FIXED HAMMER MILL

The FR 1216 mill is available in two versions:

• 560 kW (760 HP) motors;

• 710 kW (965 HP) motors.

It is suitable for a diverse range of production needs. The inlet opening, measuring 1600 x 550 mm, allows you to treat large volumes of ferrous materials. This mill is ideal for industrial environments and has been created to ensure top-notch performance.



ELECTRIC MOTOR POWER (kW/HP)
560/760 and 710/965
INLET OPENING DIMENSIONS (mm)
1600 x 550
FE PRODUCTION OUTPUT (t/h)
8 ÷ 20 and 10 ÷ 25
AL PRODUCTION OUTPUT (t/h)
6 ÷ 12 and 8 ÷ 18
ROTOR DIMENSIONS (ø x width mm)
1200 x 1600
STANDARD PLANT SIZE (m)
38 x 23 x 12
STANDARD PLANT WEIGHT (T)
140
