DESCRIZIONE

MM 609/120 MOBILE HAMMER MILL

The MM 609/120 mobile hammer mill is the best-performing model in the range, thanks to an electric motor that reaches a power of 90 kW (120 HP): this allows the plant to ensure maximum output while maintaining a compact and versatile layout.

Just like the other two models, the MM 609/120 mill is perfect for companies that process taps, cans and other scrap metal of small sizes and which, as a result, need machinery:

  • with a small inlet opening;
  • that can be easily integrated with separation lines and other metal refining equipment.

mobile-hammer-mill-model-609-120
model-mm-609-120-mobile-hammer-mill

FEATURES

THE MM 609/120 MILL: STRENGTHS

This model is ideal for handling and processing scrap destined for fine crushing or as the final step in production lines integrated into larger systems.

INCHES
24
DIMENSIONS (cm)
600 x 900
POWER HP
120 (KW 90)

TECHNICAL DATA

CHARACTERISTICS OF THE 609/120 MODEL

The MM 609/120 model can process between 4 and 10 tonnes of iron (FE) per hour and between 1.5 and 4 tonnes of aluminium (AL), making it, in every respect, the best-performing plant of the entire Parfer Siti mobile hammer mill range.

Read on to discover all the technical specifications of this plant!



ELECTRIC MOTOR POWER (kW/HP)
90/120
INLET OPENING DIMENSIONS (mm)
900 x 300
FE PRODUCTION OUTPUT (t/h)
4 ÷ 10
AL PRODUCTION OUTPUT (t/h)
1,5 ÷ 4
ROTOR DIMENSIONS (ø x width mm)
600 x 900
STANDARD PLANT SIZE (m)
13 X 6 X 5
STANDARD PLANT WEIGHT (T)
30
